TV Unit Cabinet with Shelves - CAD Design Detail
×
Posted By - Raj Dalal
Posted By - Raj Dalal
Description
Download this detailed AutoCAD drawing of a TV unit cabinet measuring 5'9" x 1'4" x 1'. This comprehensive CAD file features a cabinet with three equal-length drawers, made of plywood/MDF and finished with laminate or ducco paint. The floating shelves/upper cabinets above the TV unit include two open shelves measuring 1' x 1' x 1' and five shelves with uplift openable shutters of varying sizes.
This AutoCAD drawing includes working drawings and construction details, providing plans, elevations, sections, and all necessary blow-up fixing details. Perfect for architects and interior designers, this file offers precise and thorough documentation for TV unit designs.
This AutoCAD drawing includes working drawings and construction details, providing plans, elevations, sections, and all necessary blow-up fixing details. Perfect for architects and interior designers, this file offers precise and thorough documentation for TV unit designs.
Show more
Product Details
| Category | Furniture & Fixtures |
| Software | Autocad |
| File ID | 561 |
| Type | Paid |
