Pooja Room Design Mandir CAD Drawing

This AutoCAD DWG drawing presents a beautiful and functional 7'x7' traditional pooja room—perfectly suited for homes, apartments, and villas that value spirituality and style. Designed with cultural sensitivity and modern craftsmanship, it features a full wall-length wooden mandir unit with integrated storage, CNC-cut decorative panels, and ambient cove lighting- a combination that enhances both aesthetic and utility.

Design Features & CAD Detailing

Crafted for elegance and precision, the mandir structure extends to 7 feet, aligning seamlessly with standard door lintel levels for visually harmonious proportions. The back wall panel is enriched with premium laminate, a charcoal sheet background, and intricate CNC motifs, offering depth and traditional charm. A 2″ thick wooden frame at the top accommodates spotlights and bells, while the ceiling’s layered illumination—with a central chandelier and LED cove lights—sets a serene tone perfect for daily prayers and festive ceremonies.

At the base, a smart cabinet system offers three drawers plus an open shelf for pooja essentials—organised, functional, and in sync with the groove pattern used throughout the structure. This continuity in design enhances the visual flow, ensuring a professional and elegant finish.

Technical Drawings & CAD Integration

The DWG file is construction-ready, containing meticulously drafted plan views, elevations, sections, and blow-up fixing details, so architects, interior designers, and CAD professionals can integrate it seamlessly into their projects. Layered and editable, it's compatible with AutoCAD 2010 and above, cut down design time, and ready for client presentations or execution.

Applications & Benefits for Your Projects

This Pooja Room CAD Drawing offers real-world value for design professionals and homeowners:

• Time-saving starts: Drop the DWG straight into your residential layout and save hours of drafting
• Balance of tradition and utility: Delivers Vastu-aligned sacred geometry with modern storage, lighting, and spatial structure
• Adaptable to varied spaces: Ideal for apartments, villas, multi-story homes, and even compact sanctuaries
• Client-ready design: Impress clients with a detailed, culturally respectful, and visually pleasing mandir design
• When combined with other CAD resources like Modern Pooja Mandir Interior CAD Drawing, you can expand design options and accelerate project delivery

Related CAD Drawings You Can Use Together

To create a cohesive interior package, combine this Pooja Room CAD Drawing with other design resources from our library:

Wall Paneling with Groove Design AutoCAD DWG Detail – a perfect add-on to complement your pooja room’s backdrop with refined MDF paneling and modern groove detailing.

Glass Paneled Door Design Free DWG – Double & Single Shutter – integrate sleek glass door designs for pooja rooms, offices, or residential interiors.

OM Design MDF Jaali Temple Elevation CAD File – enrich your mandir with traditional jaali work, enhancing both spiritual symbolism and aesthetics.

This CAD drawing is designed and drafted by our in-house architectural design team,  reflects years of hands-on experience in both traditional interior design and digital precision. It’s not merely a file—it’s a thoughtfully crafted tool meant to support your creative vision and technical needs.
