Office Interior Layout and Details Autocad File
×
Posted By - Shubham Bansal
Posted By - Shubham Bansal
Description
Explore the comprehensive Autocad working drawing of a modern office designed on the Ground Floor within a 15x10 meter space. This detailed layout includes essential areas such as a reception cum waiting lobby, cabins of various sizes, workstations in different configurations, a meeting room, MD room, storage area, toilet facilities, and a pantry.
The drawing meticulously depicts furniture placements, flooring, ceiling designs, HVAC systems, and electrical layout plans complete with necessary legends. Perfect for office designs, this file is ideal for architects and interior designers.
The drawing meticulously depicts furniture placements, flooring, ceiling designs, HVAC systems, and electrical layout plans complete with necessary legends. Perfect for office designs, this file is ideal for architects and interior designers.
Show more
Downloads in last 24 hours
Product Details
| Category | Commercial and Retail Hubs |
| Software | Autocad DWG |
| File ID | 70 |
| Type | Paid |
