Modern Study Table AutoCAD Drawing with Storage Details
×
Posted By - Anju Singh
Posted By - Anju Singh
Description
Download this detailed AutoCAD drawing of a study table designed for optimal functionality and style. Made with plywood and finished with laminate, the table measures 8 feet in length and 7 feet in height. The working desk has a width of 2 feet and features drawer cabinetry and a drawer pedestal for ample storage. An upper storage ledge/plank with a 12-inch width is also included. To enhance the unit's overall look, a pin board is integrated into the design.
This AutoCAD drawing includes comprehensive working drawings and construction details, featuring plans, elevations, sections, an isometric view, and all necessary blow-up fixing details. Ideal for architects and interior designers, this file provides precise and thorough documentation.
This AutoCAD drawing includes comprehensive working drawings and construction details, featuring plans, elevations, sections, an isometric view, and all necessary blow-up fixing details. Ideal for architects and interior designers, this file provides precise and thorough documentation.
Show more
Downloads in last 24 hours
Product Details
| Category | Residential Spaces |
| Software | Autocad DWG |
| File ID | 966 |
| Type | Paid |
