Lift Lobby Design DWG for Multi-Storey Structures
×
Posted By - Smita Varshnay
Posted By - Smita Varshnay
Description
This AutoCAD DWG drawing offers a detailed design of a lift lobby for a multi-storey building. It includes comprehensive horizontal and vertical sections, floor plans, and blow-up details. This drawing is invaluable for architects, engineers, and designers involved in residential, commercial, or mixed-use projects. It provides clear and precise layout information, essential for the construction and planning of lift lobbies in multi-storey structures, ensuring effective and efficient design implementation.
Show more
Product Details
| Category | Construction & Standard Details |
| Software | Autocad DWG |
| File ID | 431 |
| Type | Free |
