Beauty Salon Design Full Interior DWG Layout and Details

Download these detailed AutoCAD drawings of a salon design for a space measuring 20'0" x 50'0". This comprehensive CAD file includes plans for a salon with an industrial, raw ambiance, featuring exposed brick panels, fluted wooden strips, and industrial hanging lamps.

The salon layout is meticulously divided into distinct functional areas: a reception-waiting area, hair wash and haircut zones, manicure-pedicure area, facial cabins, changing room, pantry, staff locker room, and washroom. The reception and waiting areas are strategically positioned on either side of the center entrance. The layout ensures that each functional space flows seamlessly into the next.

On the right side, you'll find the reception area, haircut area, manicure-pedicure area, two facial cabins, staff locker/storage room, and washroom. The left side houses the waiting area, haircut area, hair wash area, two facial cabins, changing room, and pantry. Storage space is efficiently planned between the pantry and washroom.

The elevation of wall A includes a backspace with storage and an above-lintel-level slit window for ventilation. Wall B features the reception area with a back wall panel finished in laminate, a circular logo, cove lighting, and floating shelves. The reception counter is crafted from plywood with a fluted panel, wooden strips, laminate, a wooden border, and a Corian countertop.

Wall C highlights the waiting area with an exposed brick panel, wallpaper, artifacts, cove lighting, floating shelves for planters, and a sofa for seating. Wall D includes the entrance door and a slit window above the lintel for ventilation.

This drawing set includes working drawings, construction details, plans, elevations, sections, and all necessary blow-up fixing details.
