25'x50' House Space Plan- 2 BHK Ground Floor & Flats - CAD
×
Posted By - Naveen singh
Posted By - Naveen singh
Description
This AutoCAD drawing showcases the space planning of a house on a 25'x50' plot. The ground floor is designed as a 2 BHK house with an open front area and an external staircase. The first floor contains two separate 2-bedroom flats, one located at the front and the other at the back of the building. This DWG file is ideal for architects and designers working on residential projects, providing a clear layout for efficient space utilization. It can be used for residential properties where multiple living units are planned on a compact plot.
Show more
Product Details
| Category | Residential Spaces |
| Software | Autocad DWG |
| File ID | 1882 |
| Type | Paid |
